Verified application · Machine Tools
Precision spindle and ATC transmission
A precision transmission package for CNC spindle and automatic tool-changer mechanisms, focused on gear quality, runout control, locking reliability and repeatable documentation.
Customer context
A machine-tool builder needed transmission components for spindle and ATC mechanisms where noise, runout and locking reliability directly affected machine perception. The customer required custom parts, but also needed a quality package that could support repeated builds.
Application challenge
Three constraints that define performance
Wolfer solution package
Review every critical interface as one drivetrain
- Ground spindle gears with controlled profile, lead and contact behavior.
- ATC gear shafts and custom machined transmission parts made to drawing.
- Keyless locking assemblies for repeatable torque transfer and easier service.
- Couplings and hub interfaces reviewed for runout and assembly stability.
Engineering approach
From drawing review to inspection release
Aligned gear and shaft inspection datums with spindle bearing and mounting references.
Reviewed locking assembly fit, surface finish and shaft tolerance before production.
Prepared inspection records for repeat orders and machine-series builds.
Validation evidence
Validation records available with delivery
- ✓Gear inspection report for profile, lead, pitch and runout.
- ✓CMM report for shaft shoulders, bores and mounting features.
- ✓Material, hardness and heat-treatment records.
- ✓Locking assembly fit note and installation torque reference.
Result
Project outcome and reorder value
- The helical spindle set matched the Japanese OEM part at the same precision class — at 56% lower cost, with repeat lots shipped for 3 years.
- The ATC worm pair, hand-paired and lapped, held 0.02 mm angular repeatability across a 32-tool magazine.
- Tooling is held for five years, so established part numbers re-order in 15–20 days instead of 30.
VERIFIED OUTCOME
Precision spindle and ATC transmission with a reusable quality baseline
For CNC spindles and automatic tool changers, gears, gear shafts and locking interfaces are machined and inspected to the same assembly datums. Ground spindle gears can reach ISO 6; the 32-station ATC worm set holds 0.02 mm angular repeatability, and mature part numbers can be reordered against the established quality baseline.
ISO 6
Ground spindle-gear accuracy
0.02 mm
32-station ATC angular repeatability
15–20 days
Repeat-order lead time for mature part numbers
Information needed to start
Prepare these inputs for a faster engineering review and quotation
- Gear drawing, spindle speed range, torque load and required accuracy class.
- Shaft, bore, keyway and locking assembly interface details.
- Noise, runout, balancing or inspection documentation requirements.
